All you need in one system MyPBX U100 is a 1U rack mount model IP PBX for up to 100 users. Internally, it supports network access to ISDN BRI, PSTN, GSM/UMTS and VoIP. High performance, stability and compatibility, combined with rich functionality make MyPBX U100 perfectly suited for your business communication. - See more at: http://www.yeastar.com/Products/MyPBX-U100.asp#sthash.lYovLAQw.dpuf
- Internal Construction
- Specification Features Users: 100
- Concurrent Calls: 25
- Voicemail: Default 3000min (upgradable)
- Auto-Recording(Add-on): Support
- Interface:
- Up to 16 Analog Ports (FXO/FXS)
- Up to 8 GSM Ports (Quad-Band GSM/GPRS850/900/1800/1900MHz)
- Up to 8 UMTS Ports (UMTS 900/2100MHz or 850/2100MHZ or 850/1900MHZ)
- Up to 8 BRI Ports
- One RS232 Port
- LAN: 1 (10/100Mbps)
- WAN: 1 (10/100Mbps)
- USB: 1 (USB2.0)
- Audio In/Out: Supported
- Size: 340x210x44 mm
- Weight: 2.1kg
- Power Supply: AC 100-240V 50/60Hz 1.5A MAX
-
SIP Protocol: SIP(RFC3261), IAX2 - Transport Protocol: UDP,TCP,TLS,SRTP
- Codec: G.711, GSM, SPEEX, G.722, G.726, ADPCM, G.729 A, H261,
- H263,H263p, H264 ,MPEG4.
- DTMF: Inband, RFC2833, SIP INFO
- Echo Cancellation: Supported
- LED: Red for FXO/GSM/UMTS, Orange for BRI, Green for FXS
- Network: Static IP, PPPoE, DHCP, Firewall, VLAN, DDNS, QoS,
- DHCP Server,OpenVPN
- Multiple Languages Support:
- Chinese, Dutch, English, French, German, Hebrew, Korean, Italian,
- Polish,Portuguese, Romanian, Russian, Spanish, Thai, Turkish
- Internal Construction
- Attend Transfer
- Blind Transfer
- BLF Support
- Blacklist
- Callback
- CDR (Call Detail Records)
- Call Forward
- Call Parking
- Call Recording
- Call Pickup
- Call Routing
- Call Transfer
- Call Waiting
- Caller ID
- Conference
- Define Office Time
- DDNS
- Dial by Name
- DISA (Direct Inward System Access)
- DIDs
- Distinctive Ringtone
- DND (Do Not Disturb)
- FAX (T.38)
- Firewall
- Follow Me
- IVR (Interactive Voice Response)
- Intercom/Zone Intercom
- Mobility Extension
- Multi-language Prompt
- Music On Hold
- Music On Transfer
- MyTwins (Double System)
- One touch record
- OpenVPN
- Phone Provisioning
- PIN User ( PIN Code Control)
- Paging/Zone Paging
- PPPoE
- Queue
- Redundancy
- Ring Group
- Route by Caller ID
- Skype Integration (Skype Connect)
- SMS to Mail/Mail to SMS
- Speed Dial
- Three Way Calling
- Voicemail
- Voicemail to Email
- Voicemail Forwarding
- Web Based Control Panel
- Spy functions (Normal Spy, Whisper Spy, Barge Spy)
